Allen & Heath Qu-6 / Qu-6D 38-Input 96kHz Digital Mixing Console
Allen & Heath Qu-6 / Qu-6D 38-Input 96kHz Digital Mixing Console
The Allen & Heath Qu-6 / Qu-6D is a next-generation professional digital mixing console featuring 96kHz XCVI processing, 38 input channels, 25 motorized faders, and a 7-inch touchscreen. Designed for live sound, touring, houses of worship, corporate AV, and permanent installations, the Qu-6 series combines powerful mixing capabilities with expanded hands-on control.
Key Specifications
38 Inputs to Mix – 32 Mono/Linkable + 3 Stereo
96kHz XCVI Processing with DEEP Processing Support
25 × 100mm Motorized Faders with 4 Customizable Layers
24 Local Mic/Line Inputs and 16 XLR Outputs
7" Capacitive Touchscreen and Assignable SoftKeys
128×128 SLink Expansion and 32×32 USB-C Audio Interface
Integrated 16×16 Dante Connectivity on Qu-6D Model
Select your model: Qu-6 (Standard) or Qu-6D (Dante Enabled).
Shipping & Pickup
- Nationwide shipping available.
- Professionally packed for safe transport.
- Local pickup available in Phillipsburg, NJ.
Product Overview
The Allen & Heath Qu-6 and Qu-6D are next-generation professional digital mixing consoles combining a 96kHz XCVI processing engine with expanded physical connectivity and hands-on mixing control. Both models provide 38 inputs to mix, 12 mixes, 4 matrix outputs, 6 FX engines, and support for DEEP Processing, making them ideal for live sound, touring, houses of worship, corporate AV, and permanent installations.
With 24 local XLR/TRS combo inputs, 16 XLR outputs, 25 motorized faders, four customizable layers, and a 7-inch touchscreen, the Qu-6 series provides intuitive operation and flexible signal routing. Additional features include Gain Assistant, Feedback Assistant, Automatic Mic Mixer, 128x128 SLink expansion, 32x32 USB-C audio interfacing, and SD card multitrack recording.
Model Options: The Qu-6 provides the standard digital mixing platform with SLink expansion. The Qu-6D includes all standard Qu-6 features plus an integrated 16x16 Dante interface operating at 48kHz or 96kHz through a dedicated locking etherCON network port.
Technical Specifications
| Models | Qu-6 / Qu-6D |
| Mixer Type | Professional Digital Mixing Console |
| Processing Engine | 96kHz XCVI Core |
| Input Channels | 38 (32 Mono/Linkable + 3 Stereo) |
| Local Mic/Line Inputs | 24 XLR/TRS Combo Sockets |
| Stereo Line Inputs | 2 Stereo Inputs (4 TRS Sockets) |
| Local XLR Outputs | 16 XLR Outputs |
| Additional Outputs | 2 TRS Outputs + Stereo AES3 Digital Output |
| Mix Buses | 12 Mixes + Stereo Main LR |
| Matrix Outputs | 4 Mono/Linkable Matrix Mixes |
| Motorized Faders | 25 x 100mm, 4 Customizable Layers |
| Display | 7" Capacitive Touchscreen |
| Assignable Controls | 8 SoftKeys |
| Effects Processing | 6 Multi-FX Engines with Stereo Returns |
| Processing Features | DEEP Processing Ready, Gain Assistant, Feedback Assistant, Automatic Mic Mixer |
| SLink Expansion | 128x128 Intelligent SLink Port |
| Dante Connectivity | Qu-6D Only: Integrated 16x16 Dante at 48/96kHz |
| USB Audio Interface | 32x32 USB-C at 48/96kHz |
| SD Card Recording | 32 Channels at 48kHz / 16 Channels at 96kHz |
| Remote Control | Qu-MixPad and Qu4You Apps |
